Antena Transponder/DME Rami AV-74 TSO
R$2.359,12
Antena Rami AV-74 TSO, Alternada da Comant CI-105
1Vendido(s)
Compre material aeronáutico com segurança
- Compra Segura
- Diversos meios de pagamento
- Disponível 24h, sem depender de Whatsapp
Descrição
Antena Rami AV-74 TSO, Alternada da Comant CI-105
The AV-74 (.425 Stud Length) is a broadband blade type antenna for transponders or DME application. The antenna housing is constructed of an acrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt. The antenna is supplied with cellular neoprene mounting pad and hardware. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. It has a drag force of 0.09 lbs @ 250 mph. This antenna is a direct replacement for the CI-105.
- Application: Transponder/DME
- Frequency: 960 – 1220 MHz
- Impedance: 50 Ohms Nominal
- VSWR: 1.5:1 Maximum
- Polarization: Vertical
- Pattern: Omni-Directional
- Connector: “BNC” Female
- Max Height: 3.4″
- RF Power Capacity: 2.5 kW Peak
- FAA TSO: C66c, C74c
Informação adicional
| Peso | 1 kg |
|---|---|
| Dimensões | 20 × 20 × 20 cm |
